Gallery

Hamburg Vorwerk-Logstor

At our site in Hamburg we bent a 16m long DN800/1100 pipe to over 20°, setting a new world record!

Sondershausen Isoplus

Celle

Misc

Immediately after bending, the pipes are ready to be lowered into the trench. As here on our site in Martigny, Switzerland. Pipes bent by us compared to KMR pipe unbent by us.

Pipes we can bend



In addition to district heating pipes, we also bend pipeline pipes without thermal insulation. We bend all regular pipe sizes according to API5L specifications with bending radii of 40xD for longitudinally welded pipes and 75% of 40xD for spiral welded pipes.



Our bending process is certified by the FFI (FernwärmeForschungs-Institut) and meets the requirements of DIN EN 253:2020-03.





Nominal
diameter
(DN)		 Straight ends (m) Longitudinal welded pipe
(75% of bending angle on spiral welded pipes)
Minimum bending
radius (m)		 12m pipe 16m pipe
Bending angle (°) Plan radius (m) Bending angle (°) Plan radius (m)
100 0,49 4,57 138,2 4,76 188,3 4,54
150 0,62 6,73 91,6 7,34 125,6 7,05
200 0,75 8,76 68,7 9,86 94,8 9,45
250 0,88 10,92 53,7 12,66 74,7 12,08
300 1,01 12,96 44,1 15,45 61,8 14,64
350 1,09 14,22 39,6 17,25 55,7 16,29
400 1,22 16,26 33,7 20,27 47,8 19,00
450 1,34 18,28 29,2 23,43 41,7 21,80
500 1,47 20,32 25,5 26,80 36,8 24,74
550 1,60 22,35 22,6 30,35 32,8 27,77
600 1,73 24,40 20,1 34,14 29,5 30,96
650 1,85 26,40 18,0 38,07 26,7 34,20
700 1,98 28,44 16,2 42,33 24,3 37,64
750 2,11 30,48 14,6 46,86 22,2 41,23
800 2,20 32,52 13,4 51,26 20,4 44,72
850 2,20 34,56 12,6 54,49 19,2 47,55
900 2,20 36,56 11,9 57,65 18,2 50,31
1000 2,20 40,64 10,7 64,10 16,4 55,95

In addition to the listed pipe variants, other bends are also possible.
